Our tech stack is latest, modular, robust, and highly scalable.

Front end UI

  • HTML 5.0
  • CSS 3
  • JavaScript / JQuery
  • Web Sockets
  • Nginx (Web server)
  • Angular 16

Server Platform

  • Java 11.0.8
  • Spring 5.1.8
  • Hibernate 5.0.8 (ORM framework)
  • Tomcat 9.0.41 (Application Server)
  • Play Server 2.7.1
  • Kibana – Visualization Framework
  • Coturn 4.5.2 (Turn Server)

DB Server

  • MySQL 5.7, Maria DB (Database)
  • Redis 5 (Caching)
  • Elastic Search 7 (Search engine)

AWS infrastructure components and services used for a dedicated tenant deployment

Type
Instance Type / Service Details
CPU (Core)
RAM (GB)
Disk (GB)
OS / Service
Web Load Balancer (Web LB)
Application Load Balancer (ALB)
-
-
-
Managed Service
Turn Load Balancer (Turn LB)
Network Load Balancer (NLB)
-
-
-
Managed Service
Internal Application Load Balancer (App LB)
Application Load Balancer (ALB)
-
-
-
Managed Service
Web Server
EC2 - c5.large
2
4
200
Linux Redhat 8.9
Application Server
EC2 - c5.2xlarge
8
16
300
Linux Redhat 8.9
Relational Database (RDS - MySQL)
db.m5.large (with multi-AZ)
4
16
200
Managed Service
Elastic Cache Redis
cache.t2.medium (with multi-Az)
2
8
100
Managed Service
Elastic Search
t2.small.elasticsearch (with Multi AZ)
2
8
500
Managed Service
Turn Server
EC2 - c5.large
2
4
200
Linux Redhat 8.9
File Storage (per Month)
S3
-
-
600
Managed Service
Temporary Video File Storage
Elastic File system (EFS)
-
-
500
Managed Service
AWS recognition
2 API Calls per KYC
-
-
-
Managed Service

Software requirement for a dedicated tenant deployment

Component
Software
Provided by
Load Balancer
LB
AWS Service
Web Server
Nginx 1.18
VideoCX.io
Web and Application Server - Machine OS
Linux Redhat 5.7
EC2 VM
Video Server  - Machine OS
Linux Redhat 5.7
EC2 VM
Platform
Java 11.0.8
VideoCX.io
Application Server
Tomcat 9.0.38, Play Server 2.7.1
VideoCX.io
Video Server
Coturn 5.1.0.8, Janus Server
VideoCX.io
DB Server
Azure Database for MySQL 5.7
AWS Service
Caching Server
Azure Database for Redis 5
AWS Service
Monitoring DB Server (VM)
Linux Redhat 5.7
EC2 VM
File Storage
Blob Storage, File Share
AWS Service
Backup
File Storage
AWS Service

* All VideoCX.io software are open source
